| Processor | Industrial-grade Processor |
| Operating System | Embedded LINUX |
| IP Camera Input | 8 channel |
| User Interface | GUI,WEB Interface |
| AI by Camera | Face detection, Face recognition, Perimeter protection, SMD Plus, People counting, Stereo analysis, Heat map |
| AI by NVR | SMD+ |
| Perimeter Performance of AI by Camera (Number of Channels) | 6 Ch. |
| Face Recognition Performance of AI by Camera | 6 ch. |
| SMD Plus by Camera | 6 ch. |
| Face Detection Performance of AI by Camera (Number of Channels) | 6 ch |
| Video Output | 1 HDMI, 1 VGA Simultaneous： HDMI: 3840 × 2160, 1920 × 1080, 1280 × 1024, 1280 × 720 VGA: 1920 × 1080, 1280 × 1024, 1280 × 720 Heterogeneous： HDMI: 1920 × 1080, 1280 × 1024, 1280 × 720 VGA: 1920 × 1080, 1280 × 1024, 1280 × 720 |
| Face Attributes | Gender; Age group; Glasses; Expressions; Face mask; Beard |
| SMD Plus by NVR | 4 channels: Secondary filtering for human and motor vehicle, reducing false alarms caused by leaves, rain and lighting condition change |
| Network Bandwidth | AI disabled: 160 Mbps incoming, 160 Mbps recording and 80 Mbps outgoing AI enabled: 80 Mbps incoming, 80 Mbps recording and 60 Mbps outgoing |
| Resolution | 12 MP; 8 MP; 6 MP; 5 MP; 4 MP; 3 MP; 1080p; 960p; 720p; D1; CIF; QCIF |
| Video Compression | H.265/H.264 |
| Encode Strategy | Instastream |
| Decoding Capability | AI disabled: 1-channel 12 MP@30 fps; 2-channel 8 MP@30 fps; 3-channel 5 MP@30 fps; 4-channel 4 MP@30 fps; 8-channel 1080p@30 fps AI enabled: 1-channel 12 MP@30 fps; 1-channel 8 MP@30 fps; 2-channel 5 MP@30 fps; 3-channel 4 MP@30 fps; 7-channel 1080p@30 fps |
| Audio Input | 1Ch. RCA |
| Audio Output | 1Ch. RCA |
| Audio Compression | G.711a; G.711u; PCM; G726 |
| Alarm Input | 4Ch. |
| Alarm Output | 2Ch. |
| Disk Group | Support |
| Smart Phone | iPhone, iPad, Android Phone |
| Disk Interface | SATA ports. Each disk can contain up to 20 TB. This limit varies depending on the environment temperature. |
| General Alarm | Motion detection, privacy masking, video loss, scene changing, PIR alarm, IPC external alarm |
| Anomaly Alarm | Camera disconnection, storage error, disk full, IP conflict, MAC conflict, login locked, and cybersecurity exception |
| Intelligent Alarm | Face detection; face recognition; perimeter protection; SMD Plus; people counting; stereo analysis; heat map |
| Alarm Linkage | Record; snapshot; IPC external alarm output; audio; buzzer; log; preset; email |
| Recording Mode | General, motion detection; intelligent; alarm |
| Protocols | HTTP; HTTPS; TCP/IP; IPv4; IPv6; UDP; NTP; DHCP; DNS; SMTP; UPnP; IP Filter; FTP; DDNS; SNMP; Alarm Server; Auto Registration; IP Search,ONVIF 22.12(Profile T; Profile S; Profile G); CGI; SDK |
| Playback Function | Instant playback, General playback, Event playback, Tag playback, Smart playback |
| Multi-channel Playback | 8 Ch. |
| Multi-screen Display | Main Screen: 1/4/8/9, Sub Screen: 1/4/8/9 |
| Browser | Chrome; IE; Safari; Edge; Firefox |
| Backup Mode | USB device and network |
| Interface Ports | 2 (1 × front USB2.0; 1 × back USB2.0) |
| Ethernet | 1 × RJ-45, 10/100/1000 Mbps self-adaptive Ethernet port |
| PoE | 8 ports, 10/100 Mbps, IEEE 802.3 af/at |
| Operating Temperature | –10 °C to +55 °C (+10 °F to +131 °F) |
| Operating Humidity | 10℅~93℅ |
| Storage Temperature | –20 °C to +60 °C (–4 °F to +140 °F) |
| Power Supply | 100–240 VAC, 50/60 Hz |
| Power Consumption | Total output of NVR is |
| Dimension | 1U, 375.0 mm × 327.9 mm × 53.0 mm (W×L×H) |
| Weight | 2.47 kg |
