| Processor | Industrial-grade processor |
| IP Camera Input | 32 Channel |
| Operating System | Embedded LINUX |
| User Interface | Web, Local GUI |
| Video Output | 1-channel VGA, 1-channel HDMI video output. HDMI: 3840 × 2160, 1920 × 1080, 1280 × 1024, 1280 × 720 VGA: 1920 × 1080, 1280 × 1024, 1280 × 720 *Simultaneous/heterogeneous video sources output for VGA and HDMI is configurable. |
| Compression | H.265, H.264, MJPEG |
| Encode Strategy | Instastream |
| Decoding Capability | AI disabled: 2-channel 16 MP@30 fps, 2-channel 12 MP@30 fps, 4-channel 8 MP@30 fps, 6-channel 5 MP@30 fps, 8-channel 4 MP@30 fps, 16-channel 1080p@30 fps AI enabled: 1-channel 16 MP@30 fps, 2-channel 12 MP@30 fps, 3-channel 8 MP@30 fps, 4-channel 5 MP@30 fps, 6-channel 4 MP@30 fps, 12-channel 1080p@30 fps |
| AI by NVR | Face detection; face recognition; perimeter protection; SMD Plus |
| Resolution | 32 MP; 24 MP; 16 MP; 12 MP; 8 MP; 5 MP; 4 MP; 1080p; 720p; D1; CIF; QCIF |
| Network Bandwidth | 32 MP; 24 MP; 16 MP; 12 MP; 8 MP; 5 MP; 4 MP; 1080p; 720p; D1; CIF; QCIF |
| Video Display Split | Main screen: 1/4/8/9/16/25 Sub screen: 1/4/8/9/16 |
| Perimeter Performance AI by NVR (Number of Channels) | 2 channels, 10 IVS rules for each channel |
| Perimeter Performance of AI by Camera (Number of Channels) | 16 channels |
| Face Attributes | Gender; age group; glasses; expressions; face mask; beard |
| Face Detection Performance of AI by Recorder (Number of Channels) | 2 channels (up to 12 face images/s each channel) |
| Face Detection Performance of AI by Camera (Number of Channels) | 8 channels |
| Face Database Capacity | Up to 20 face databases with 10,000 images, with a total capacity of 2.5 G. Name, gender, birthday, address, credential type, credential No., countries & regions and state can be added to each face image. |
| Face Recognition Performance of AI by Camera (Number of Channels) | 16 channels |
| SMD Plus by NVR | 8 channels: Secondary filtering for human and motor vehicle, reducing false alarms caused by leaves, rain and lighting condition change |
| SMD Plus by Camera | 16 channels |
| Metadata Performance of AI by Camera (Number of Channels) | 16 channels |
| Human Attributes | Top color, top type, bottom color, bottom type, hat, bag, age, gender and umbrella |
| License Plate Database Capacity | 1. Create up to 20,000 plate numbers. 2. Blocklist and allow list |
| Alarm Linkage | Record, snapshot, IPC external alarm output, audio, buzzer, log, preset, email |
| Audio Input | 1-channel RCA |
| Audio Output | 2-channel RCA |
| Audio Compression | G.711a, G.711u, PCM, G726, AAC |
| Disk Group | Support |
| Hard Disk | 4 SATA ports, up to 16TB each. The maximum HDD capacity varies with environment temperature |
| Multi-channel Playback | Up to 16 channels |
| Record Mode | General, motion detection; intelligent; alarm; POS |
| Playback Mode | Instant playback, general playback, event playback, tag playback, smart playback (face and motion detection) |
| Smart Phone | iPhone, iPad, Android Phone |
| Interface Ports | 3(1 front USB 2.0 port, 2 rear USB 3.0 ports), 1 HDMI, 1 VGA, 1 RS232, 1 eSATA Port, 1 RS485 |
| Protocols | HTTP, HTTPS, TCP/IP, IPv4/IPv6, RTSP, UDP, SNMP, NTP, DHCP, DNS, SMTP, UPnP, IP Filter, PPPoE, FTP, DDNS, Alarm Server, IP Search, DH, Multicast, InstaOn cloud, Auto Registration, ONVIF 21.12(Profile T, Profile S, Profile G) |
| Ethernet | 2 (10/100/1000 Mbps Ethernet port, RJ-45) |
| Power Supply | 100–240 VAC, 50-60 Hz |
| Power Consumption | ≤ 10 W (without HDD) |
| Operating Temperature | -20 °C to +60 °C (–4 °F to +140 °F) |
| Operating Humidity | 10%–93% (RH) |
| Storage Temperature | -20 °C to +60 °C (–4 °F to +140 °F) |
| Dimensions | 440.0 mm × 415.1 mm x 70.0 mm |
| Weight | 4250 g (without HDD) |
